• Explosion-proof

  • Не

• Degree of protection (IP)

  • IP20

• Voltage type

  • AC

• Additional equipment possible

  • Не

• Rated impulse withstand voltage Uimp

  • 4 kV

• Built-in depth

  • 44 mm

• Pollution degree

  • 2

• Width in number of modular spacings

  • 1

• Rated insulation voltage Ui

  • 500 V

• Rated current

  • 25 A

• Rated voltage

  • 230

• Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V

  • 6 kA

• Concurrently switching neutral conductor

  • Не

• Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V

  • 6 kA

• Number of protected poles

  • 1

• Frequency

  • 50
  • 60

• Number of poles (total)

  • 1

• Current limiting class

  • 3

• Flush-mounted installation

  • Да

• Release characteristic

  • B
